Emcor Enclosures:
Emcor's official Visio collection includes shapes for their line of quality modular enclosure systems.
|
|
|
| Collection News |
28-Aug-2007
- FP2 Front View.vss
- Added shapes for Flat Panel Display Consoles.
- FP2 Plan View.vss
- Added plan view shapes for Flat Panel Display Consoles.
- Various updates to all other files |
11-Mar-2005
- Flat_Panel_Display_Consoles-Plan_View.vss
- Added plan view shapes for Flat Panel Display Consoles.
- Flat_Panel_Display_Consoles.vss
- Added shapes for Flat Panel Display Consoles.
- Various updates to all other files |
28-Jan-2005
- Added a new set of stencils for Emcor Enclosures for their 10 series and ESQ series frames and accessories.
- Also included is a Template drawing page with page settings tuned for the stencils |
|
| Full Zip Set of Stencils (Created by Visimation) |
Emcor_Enclosures_Visio_Shape_Library |
Full set of Emcor Enclosures' Stencils |
4,033KB |
28-Aug-2007 |
|
Collection is compatible with Visio versions 2003 to 2013. Stencil folder is My Documents\My Shapes\ (Path names vary for non-US English versions)
These stencils work best for any scale templates from 1:2 to 1:30 but NOT Visio's "Blank Page" which is 1 to 1 (no-scale)
Visio's "Blank page" causes much frustration. Use our
templates instead, they have all the right settings to make Visio much easier. |
|
|
|
